JPL-298 전압 스파이크 발생기

10.1 inch capacitive touch screen, based on Android development

측정규격: MIL-STD 1275D

목록보기

Typical application scenarios

The specially designed generator with 28V DC power supply characteristics of the proposed military vehicle can perform the peak pulse voltage test on the vehicle equipment, in line with the standards GJB298-1987 and MIL-STD 1275D. Suitable for GJB298 spike voltage test.

Key features

1. The host adopts 10.1-inch capacitive touch screen and built-in Android control system.

2. Data storage interface USB.

3. Support test parameter cruise function, open test program setting.

4. Built-in file management system, support U disk reading and writing, can easily import, export and save related programs and test reports.

5. It has the functions of EUT failure detection, power supply circuit safety interlock and emergency button reset.

6. The indication function area can display the system running status in real time.

7. Customize test settings, wide range can be set.

Main technical indicators

Model	JPL-298
Maximum operating voltage	DC 0-40V	Pulse voltage	0-300V
Maximum output current	100A	Pulse front	<50 ns
Repetition period	5ms-1000ms	Pulse polarity	positive, negative, first positive, first negative, then positive
Number of iterations	1 to 9999 order	Pulse oscillation frequency	100KHz-500KHz
Pulse energy	≥15mJ
Explanation: Coupled network built in, DC Power Supply
